Firesleeve, First
• Materials: Fiberglass, Silicone Rubber
• Working Temperature: Continuous working at 500°F (260°C), peaks at 3000°F (1650°C)
• Size Range: 3/8” (10mm) – 12” (305mm) inner diameter
HANTAI Fire Sleeve First Grade (AS 1072) | UL-Certified High-Temperature Protection for Industrial Hoses & Cables. Ideal for aerospace, foundries, oil & gas—waterproof, chemical-resistant, and fully customizable.
DESCRIPTION
HANTAI Firesleeve First Grade, also known as aerospace firesleeve (AS 1072 standard), is made of high quality texturized fiberglass braided sleeve with thick upgraded silicone rubber coating. It delivers better thermal insulation performance than the Firesleeve Priority. HANTAI Firesleeve First provides superior protection for critical hoses, cables, tubes, wires and assemblies under harsh environments of high heat, flame and molten splashes, etc. Resistant to hydraulic fluids, lubricating oils and fuels, it also insulates heat transfer from hot pipe and hose systems, conserving energy while protecting personnel from injury. HANTAI Firesleeve First offers reliable system protection for different applications and industries, including aerospace, industrial engineering, foundry, automotive, transportation, defense and many others.
CHARACTERISTICS
| PROPERTY | DETAILS |
|---|---|
| PRODUCT | Firesleeve, First / Aerospace Grade Firesleeve / AS 1072 Firesleeve |
| HANTAI PART NO# | HT11S-**F (**refers to the inner diameter=ID) |
| MATERIALS | Fiberglass, Silicone Rubber |
| CONSTRUCTION | Texturized and Braided |
| SIZE RANGE | 1/4” (6mm) – 2” (50mm) |
| WORKING TEMPERATURE | Continuous working at 500°F (260°C), peaks at 3000°F (1650°C) |
| COLOR OPTIONS | Standard: Iron Oxide Red; Others: Blue, Black, Yellow, Grey, etc. on request |
| ROLL LENGTH | 20 meters / roll |
| AVAILABLE OPTIONS | Special bulk packaging (maximize productivity/minimize waste) Pre-cut short length Custom printing |
| TYPICAL INDUSTRIES | Aerospace, Foundries, Hose Fabrication, Oil & Gas, OEM, Locomotive |
APPLICATION
| HANTAI Firesleeve First Grade Frequently Asked Questions |
|---|
| Q1: What makes the HANTAI First Grade Firesleeve different? |
| Often referred to as Aerospace Firesleeve (AS1072 standard), the First Grade features a high-density texturized fiberglass braided inner layer with an extra-thick, upgraded silicone rubber coating. It provides superior thermal insulation and molten splash protection compared to the Priority Grade, making it ideal for the most demanding industrial environments. |
| Q2: What is the maximum temperature this firesleeve can withstand? |
| It is engineered for extreme heat, supporting a continuous working temperature of 500°F (260°C). It can also withstand instantaneous molten metal splashes and flame impulses at peak temperatures up to 3000°F (1650°C). |
| Q3: Does it protect against industrial oils and chemicals? |
| Yes. The heavy-duty silicone coating is completely resistant to hydraulic fluids, lubricating oils, and fuels. Beyond chemical protection, it also acts as an energy saver by insulating hot piping systems and protects personnel from burn injuries caused by hot hoses. |
| Q4: Which industries typically use the First Grade Firesleeve? |
| Due to its premium protection grade, it is widely used in Aerospace, Foundries, Oil & Gas, Steel Mills, OEM, and Locomotive industries to safeguard critical hoses, cables, and wires from extreme thermal hazards. |
| Q5: Does HANTAI First Grade Firesleeve meet international safety standards? |
| Absolutely. Our First Grade firesleeve is manufactured to meet the rigorous SAE AS1072 aerospace standards. It is designed to be self-extinguishing and provides excellent resistance to abrasion, ozone, and UV, ensuring long-term reliability and compliance in high-risk applications. |
